Races | 23 |
Drivers' Titles | 0 |
Constructors' Titles | 0 |
Victories | 0 |
Poles | 0 |
Fastest Laps | 2 |
Podiums | 0 |
Points | 92 |
Laps | 2529 |
Laps Led | 18 |
One/two finishes | 0 |
CHASSIS
Carbon fibre composite monocoque with Zylon legality side anti-intrusion panels.
SUSPENSION
Aluminium uprights with carbon fibre composite wishbones, track rod and pushrod. Inboard chassis mounted torsion springs, dampers and anti-roll bar assembly.
WHEELS
BBS Front : 18” x 13.2” – Rear: 18” x 16.9”
CLUTCH
AP Racing
TYRES
Pirelli P Zero
BRAKE SYSTEM
Brembo brake calipers and in-house design brake by wire system with carbon fibre discs and pads
ELECTRONICS
FIA single ECU with in-house design electrical harness
OVERALL WIDTH
2000mm
WHEELBASE
3600mm max
OVERALL WEIGHT
Overall vehicle weight 798kg (including driver, excluding fuel) Weight distribution between 44.5% and 46.0%
ENGINE PU SPEC
Mercedes-AMG F1 M15 E Performance. 1.6l V6 Turbo charged & energy recovery system.
TRANSMISSION
Mercedes F1 eight-speed, semi-automatic
