Sponsors: Denim, Saima TRANSMISSION Gearbox: Hewland FGB five-speed Driveshafts: Osella Clutch: Borg & Beck CHASSIS Front suspension: Top rocker arms, lower wishbones, inboard springs Rear suspension: Top rocker arms, lower wishbones, inboard springs Suspension dampers: Koni Wheel diameter: front: 13 in, rear: 13 in. Wheel rim widths: front: 11 in, rear: 16.5 in. Tyres: Michelin Brakes: Brembo Brake pads: Ferodo Steering: Osella/Knight Radiators: Osella (water)/IPRA (oil) Fuel tank: Pirelli Battery: Magneti Marelli Instruments: Smiths DIMENSIONS Wheelbase: 103.94 in./2640 mm Track: front: 68.11 in./1730 mm rear: 65.75 in./1670 mm Gearbox weight: 126 lb/57 kg Chassis weight (tub): 88 lb/40 kg Formula weight: 1301 lb/590 kg Fuel capacity: 41 gal./185 litres Fuel consumption: 4.9-6 mpg – 47-57 litres/100 km ENGINE Type: Ford Cosworth DFV No. of cylinders: V8 Bore and stroke: 85.6 mm x 64.8 mm Capacity: 2993 cc Compression ratio: 12:1 Maximum power: 470 bhp (minimum) Maximum rpm: 11,100 Valve sizes: 34.50 mm x 2/29 mm x 2 Valve lift: 10.4 mm Valve timing: 102° Pistons and rings: Cosworth Bearings: Vandervell Fuel injection: Lucas Ignition system: Lucas/Contactless Weight: 360 lb/163 kg Fuel and oil: Valvoline Sparking plugs: Champion
Races
15
Race Starts
7
Drivers' Titles
0
Constructors' Titles
0
Victories
0
Poles
0
Fastest Laps
0
Podiums
0
Points
0
Laps
318
One/two finishes
0
StatisticsGPs134Specifications
